Thickness and Weight of Chevron Conveyor Belt
|
No. of Ply |
Thickness [mm.] |
Thickness including chevron height [mm.J |
Weight per Sq.Meter (Kgs.) |
|
2 |
6 |
11 |
8.8 |
|
3 |
7 |
12 |
10.10 |
|
4 |
9 |
14 |
12.74 |
|
5 |
10 |
15 |
14.04 |
|
6 |
12 |
17 |
16.64 |
Chevron Conveyor Belt Properties
|
Belt Properties |
P |
N |
M |
OR1 |
OR2 |
HR 100 |
HR120 |
HR150 |
||
|
Tensile between Top Cover and Carcass |
(Min.) |
3 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
|
Tensile between Carcass layers |
(Min.) |
N/mm. |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
|
Tensile between Bottom Cover and Carcass |
(Min.) |
N/mm. |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
|
Tensile Strength |
(Min.) |
MPa |
15 |
20 |
25 |
8 |
8 |
12 |
10 |
10 |
|
Elongation At Break |
(Min.) |
% |
350 |
400 |
450 |
350 |
300 |
350 |
250 |
250 |
|
Abrasion |
(mm3) |
|
250 |
150 |
120 |
Good |
Good |
Good |
Good |
Good |
|
Hardness |
CA |
|
60-65 |
60-65 |
60-65 |
60-65 |
60-65 |
60-65 |
60-65 |
60-65 |
|
Extension Ratio |
% |
|
0.5-1 |
0.5-1 |
0.5-1 |
0.5-1 |
0.5-1 |
0.5-1 |
0.5-1 |
0.5-1 |
|
Tear Resistance |
|
|
Good |
Very Good |
Excelent |
Good |
Good |
Good |
Good |
Good |
|
Ross Flexing' |
|
|
Good |
Good |
Good |
Good |
Good |
Good |
Good |
Good |
|
Oil Resistance |
|
|
Poor |
Poor |
Poor |
Excellent |
Excellent |
Fair |
Far |
Far |
|
Acid-Alkaline Resistance |
|
|
Poor |
Poor |
Poor |
Fair |
Fair |
Far |
Far |
Fair |
|
Operating Temperature |
(Max) |
°C |
80 |
80 |
80 |
80 |
100 |
100 |
120 |
150 |
